Aranet PRO Base Station

SKU: HMS-015

From $880.00 incl. GST

Professional Aranet environmental monitoring gateway, local data storage and web server for connecting and centrally monitoring Aranet PRO wireless sensors. Available for 12, 50 or 100 sensors.

Key features

Central gateway for Aranet PRO wireless sensors
Available in 12-sensor, 50-sensor and 100-sensor capacity versions
Receives measurements using Aranet Sub-GHz ISM-band radio
Designed for professional multi-sensor environmental monitoring
Gateway, local data storage and web server in one device
Browser-based user interface
Ethernet network connectivity
2.4 GHz Wi-Fi connectivity
Wi-Fi access-point mode
Wi-Fi client mode
Compatible with Aranet Cloud
Stores sensor measurement data locally
Up to approximately 10 years of measurement storage for 100 sensors
View and analyse measurements centrally
Export measurement data
Suitable for multi-room and multi-building monitoring
Supports configurable sensor alarms and monitoring workflows
Sensor-capacity licence can be upgraded
Optional MQTT integration available by licence
Optional Modbus TCP/IP integration available by licence
Optional BACnet IP integration available by licence
HTTPS support
Password-protected user accounts
XXTEA wireless data protection
Receiver sensitivity: -127 dBm
Compatible with Aranet PRO series sensors including Aranet4 PRO
Compact wall or desktop installation
Designed for continuous indoor operation

Sensor Capacity

Quantity

Technical data sheet Manufacturer product page

Product information

The Aranet PRO Base Station is the central hub for professional Aranet wireless environmental monitoring installations. It receives measurements from compatible Aranet PRO series sensors using Aranet Sub-GHz wireless communication and combines gateway functionality, local data storage and a web server in one device. This allows organisations to monitor multiple rooms, buildings or environmental measurement points from a central system.

The Base Station can be connected to a network by Ethernet or 2.4 GHz Wi-Fi and provides a browser-based interface for viewing, analysing and exporting sensor measurements. It can store up to approximately 10 years of measurement data for a 100-sensor installation and can also be used with Aranet Cloud.

HMS offers the Aranet PRO Base Station in 12-, 50- and 100-sensor capacity versions. The underlying system is scalable, with Aranet offering licence upgrades where additional sensor capacity is required later.

The Aranet PRO Base Station is particularly suited to schools, offices, healthcare environments, commercial buildings, warehouses and other multi-room or multi-sensor installations where individual Aranet PRO sensors need to be centrally monitored.

BrandAranet

Product typeProfessional wireless environmental monitoring base station

Pack size1 base station

StyleNetworked indoor gateway / data storage / web server

Store SKUHMS-015

Packed weightTo be confirmed

Standards & classification

The Aranet PRO Base Station is manufactured by SAF Tehnika JSC under the Aranet environmental monitoring product range.

Aranet identifies the PRO Base Station as an indoor environmental monitoring solution providing gateway, data-storage and web-server functionality.

The Base Station receives measurements from compatible Aranet PRO series sensors using Aranet Sub-GHz ISM-band radio.

Different regional radio versions are supplied according to applicable radio-frequency requirements. The appropriate regional version must be used for the country in which the system is installed.

Aranet provides separate 12-, 50- and 100-sensor capacity configurations and optional licence upgrades.

Optional third-party integrations including MQTT, Modbus TCP/IP and BACnet IP require the appropriate additional Aranet licence.

The Base Station itself does not measure CO2 or other environmental parameters. Measurements are supplied by compatible connected Aranet PRO sensors.

Fit & sizing guidance

No personal fit or sizing requirement applies to this product.

Install the Aranet PRO Base Station indoors in a suitable central location with access to power and the required network connection.

Base-station position can affect wireless communication with sensors. For larger installations, consider building construction, walls, floors, metal structures and other obstacles when choosing the location.

Compatible Aranet PRO sensors can achieve long wireless transmission distances under favourable line-of-sight conditions, but actual indoor range will depend on the building and installation environment.

For complex or large installations, appropriate site planning or a radio site survey may be useful before permanently locating sensors and the Base Station.

Directions for use

1. Select the appropriate Aranet PRO Base Station sensor-capacity version for the installation.
2. Position the Base Station in a suitable dry indoor location.
3. Connect the supplied/appropriate power source according to the Aranet installation instructions.
4. Connect the Base Station to the local network using Ethernet or configure supported 2.4 GHz Wi-Fi connectivity.
5. Access the Base Station web interface according to the Aranet Quick Start Guide.
6. Configure administrator and user access as required.
7. Pair compatible Aranet PRO sensors with the Base Station.
8. Name and organise sensors according to rooms, buildings or monitoring locations.
9. Configure measurement displays, thresholds and alerts as required.
10. Confirm that each sensor has reliable wireless communication with the Base Station.
11. Configure Aranet Cloud connectivity if cloud-based access is required.
12. Configure optional third-party integrations only where the corresponding licence has been obtained.
13. Keep Base Station firmware current in accordance with Aranet recommendations.
14. Back up or export important measurement data where appropriate.

Always follow the current Aranet Quick Start Guide and Base Station User Guide for installation, networking, security and system administration.

Warnings & use limitations

The Aranet PRO Base Station is designed for compatible Aranet PRO environmental monitoring sensors and should be configured according to the manufacturer instructions.
Use the correct regional radio-frequency version for the country of installation.
The Base Station requires a suitable power supply and network configuration.
The unit is intended for indoor use. Protect it from water, condensation, excessive dust, extreme temperatures and physical damage.
Wireless communication range depends on building construction, interference, sensor placement and installation conditions. Maximum line-of-sight range should not be interpreted as guaranteed indoor range.
Sensor-capacity limits depend on the installed Base Station licence.
MQTT, Modbus TCP/IP and BACnet IP functionality requires additional Aranet licensing.
Environmental measurements displayed or stored by the Base Station originate from connected sensors. Measurement accuracy and limitations therefore depend on the individual sensor being used.
The Base Station is not itself a smoke alarm, carbon monoxide alarm, medical device or life-safety system.
Network and user-account security should be configured appropriately for the organisation in which the system is installed.

Do not use for

Outdoor installation where exposed to rain or unsuitable environmental conditions.
Use with an incorrect regional radio-frequency configuration.
Operation outside the manufacturer environmental limits.
Use as a substitute for legally required fire, smoke, carbon monoxide or other life-safety systems.
Assuming that the Base Station itself measures environmental conditions without compatible sensors.
Connecting more sensors than permitted by the installed sensor-capacity licence.
Using licensed integration features without the appropriate Aranet licence.
Any application outside the current Aranet installation, operating and safety instructions.

Storage

Store and operate the Aranet PRO Base Station in a clean, dry indoor environment within the temperature and humidity limits specified by Aranet. Protect the unit from water, condensation, excessive dust, direct physical damage and extreme temperatures. Store disconnected equipment securely when not in use and retain the manufacturer documentation, power equipment and accessories with the Base Station.

Specifications

BrandAranet

ManufacturerSAF Tehnika JSC

ProductAranet PRO Base Station

Product typeEnvironmental monitoring gateway, local data storage and web server

Compatible sensor familyAranet PRO series

Available sensor capacities12, 50 or 100 sensors

Capacity upgradeable by licenceYes

Aranet wireless technologySub-GHz ISM band

Receiver sensitivity-127 dBm

Network portRJ45

EthernetYes

Wi-Fi2.4 GHz

Wi-Fi modesAccess point and client

Aranet Cloud compatibleYes

Local web interfaceYes

Local data storageYes

Manufacturer-stated local storage capacityUp to 10 years of measurement data for 100 sensors

Data securityXXTEA

Web securityHTTPS

User accessPassword-protected user accounts

Optional MQTT integrationYes - additional licence required

Optional Modbus TCP/IP integrationYes - additional licence required

Optional BACnet IP integrationYes - additional licence required

Power requirement12 VDC, 0.5 A

Ingress protectionIP42

Operating temperature0°C to 45°C

Operating relative humidity0% to 90%

Device dimensions170 x 107 x 26 mm

Device weightApproximately 190 g

Enclosure materialABS plastic

Indoor useYes

Retail packed dimensionsTo be physically confirmed by HMS

Retail packed shipping weightTo be physically confirmed by HMS

Frequently asked questions

What does the Aranet PRO Base Station do?

The Aranet PRO Base Station receives measurements from compatible Aranet PRO wireless sensors and provides a central gateway, local data storage and web interface for monitoring and managing those sensors.

Does the Base Station measure CO2?

No. The Base Station itself is the central gateway. CO2 and other environmental measurements are produced by compatible sensors such as the Aranet4 PRO.

Can I connect an Aranet4 PRO to the Base Station?

Yes. The Aranet4 PRO is specifically designed to communicate wirelessly with compatible Aranet PRO base stations.

How many sensors can the Aranet PRO Base Station support?

Aranet offers 12-, 50- and 100-sensor capacity versions. HMS allows you to select the required capacity when ordering.

Can I increase the sensor capacity later?

Yes. Aranet offers licence upgrades from 12 to 50, 12 to 100 and 50 to 100 sensors.

Do I need a Base Station to use one Aranet4 PRO?

Not necessarily. An Aranet4 PRO can display its own readings and can also use Bluetooth functionality. The Base Station becomes particularly useful when multiple PRO sensors need to be monitored and managed centrally.

How does the Base Station communicate with sensors?

Compatible PRO sensors use Aranet Sub-GHz ISM-band wireless communication to transmit measurements to the Base Station.

How far away can sensors be from the Base Station?

Aranet PRO wireless sensors can achieve long line-of-sight transmission distances under suitable conditions. Actual indoor range depends heavily on walls, floors, building materials, interference and sensor placement.

Does the Base Station have Wi-Fi?

Yes. The current PRO Base Station supports 2.4 GHz Wi-Fi in access-point or client mode.

Does it have Ethernet?

Yes. It includes RJ45 Ethernet connectivity.

Can measurements be stored locally?

Yes. The Base Station provides local data storage. Aranet states capacity for up to approximately 10 years of measurement data for a 100-sensor installation.

Can I access the data in a web browser?

Yes. The Base Station includes a web server and browser-based interface for viewing and managing sensor data.

Does it work with Aranet Cloud?

Yes. The Aranet PRO ecosystem supports Aranet Cloud connectivity.

Can data be exported?

Yes. The system is designed to allow measurement data to be viewed, analysed and exported.

Does it support building-management-system integration?

Aranet supports MQTT, Modbus TCP/IP and BACnet IP integrations. These integrations require additional licences.

What is the difference between PRO 12, PRO 50 and PRO 100?

The main difference is the number of Aranet PRO sensors the Base Station is licensed to support: up to 12, 50 or 100 sensors respectively.

Do I need to buy a new Base Station if I outgrow PRO 12?

No. Aranet offers sensor-capacity licence upgrades, so a compatible Base Station can be upgraded without necessarily replacing the hardware.

Is the Aranet PRO Base Station suitable for schools and offices?

Yes. A centralised PRO system is particularly useful where environmental conditions need to be monitored across multiple rooms or locations, including schools, offices and other larger facilities.

Can I use the Base Station outdoors?

The standard Aranet PRO Base Station is an indoor product and should not be exposed to rain or unsuitable outdoor conditions.

What regional version do I need in Australia?

The Base Station must use the radio version approved for the installation region. HMS supplies the appropriate Australian-compatible configuration.
